FRU Part Number Units Per

Assembly

Description

1 40H4915 1 Rail, left

2 40H4916 1 Rail, right

3 97H9754 1 Front bezel (for empty drawer position), 1 EIA unit

4 97H9755 1 Front bezel (for empty drawer position), 3 EIA units

5 97H9756 1 Front bezel (for empty drawer position), 5 EIA units

6 0375867 6 Nut clip

7 73H2932 6 Screw, rail mounting

8 00G1268 2 Screw, M4

9 1622290 2 Washer

10 08L1132 2 Anti-tilt brackets (left and right)

11 93H9156 1 Rail, left

12 93H9159 1 Rail, right

Chapter 10. Models S80 and S85 Parts
