Table 9. Operator Panel Function Codes (continued)
Function Code Function Selected
20 xxxx xxxx Reserved
21 xxxx xxxx Reserved
22 xxxx xxxx Initiates AIX dump.
23 xxxx xxxx Reserved
24 xxxx xxxx Reserved
Note: Do not use functions 25 or higher unless directed to by service support personnel.
25 xxxx xxxx The service representative switch 1 is set; this function is the
first step necessary to set the service function range from 50 to
70. This function is for service representatives only
26 xxxx xxxx The service representative switch 2 is set; this function is the
second step necessary to set the service function range from
50 to 70. This function is for service representatives only
27 xxxx xxxx through 31 xxxx
xxxx
Reserved
32 xxxx xxxx Reserved
33 xxxx xxxx Reserved
34 xxxx xxxx Reserved
35 xxxx xxxx through 49 xxxx
xxxx
Reserved
50 xxxx xxxx System processing unit stop.
51 xxxx xxxx System processing unit status. Displays the following values:
B0 register contents, System instruction address register (IAR)
address, Current task dispatching element (TDE) contents.
52 xxxx xxxx System processing unit start.
53 xxxx xxxx Path switch and reset.
54 xxxx xxxx Reserved
55 xxxx xxxx Display low-level diagnostic service processor log buffer.
56 xxxx xxxx Display low-level diagnostic service processor code area.
57 xxxx xxxx Reserved
58 xxxx xxxx Display low-level diagnostic IPL parameters area.
59 xxxx xxxx Set first character of base address for function 62 display.
60 xxxx xxxx Set second character of base address for function 62 display.
61 xxxx xxxx Set third character of base address for function 62 display.
62 xxxx xxxx Display service processor control storage.
63 xxxx xxxx System status SRC trace.
64 xxxx xxxx Service processor diagnostic status SRC trace.
65 xxxx xxxx Reserved
66 xxxx xxxx Reserved
67 xxxx xxxx Reserved
