Table 17. Current PCI 2.1 Class Code Definition (continued)

6 Bridge devices

00 Host bridge

01 ISA bridge

02 EISA bridge

03 MCA bridge

04 PCI-to-PCI bridge

05 PCMCIA bridge

06 NuBus bridge

07 Cardbus bridge

80 Other bridge device

7 Simple communication controllers

00 Serial controllers

01 Parallel port

80 Other communication controllers

8 Generic system peripherals

00 PIC

01 DMA controller

02 System timer

03 Real-Time Clock (RTC) controller

80 Other system peripherals

9 Input devices

00 Keyboard controller

01 Digitizer (pen)

02 Mouse controller

80 Other input controllers

A Docking stations

00 Generic docking station

80 Other type of docking station

B Processors

00 Reserved

01 Reserved

02 Reserved

10 Reserved

20 PowerPC

40 Co-processor

Appendix H. Interpreting Firmware Error Codes

645
