v Follow the suggested actions in the order in which they are listed in the Action column until the problem is
solved.
v If an action step is preceded by “(Trained technician only),” that step must be performed only by a trained
technician.
v Go to the IBM support website at http://www.ibm.com/supportportal/ to check for technical information, hints,
tips, and new device drivers or to submit a request for information.
Diagnostic
code Message Description Action
S.3040007 [S.3040007] A firmware fault
has been detected in the UEFI
image.
Internal UEFI Firmware Fault
Detected, System halted.
1. Check the IBM support website
for an applicable retain tip or
firmware update that applies to
this error.
2. Recover the server firmware.
I.3048005 [I.3048005] UEFI has booted
from the backup flash bank.
Booting Backup UEFI Image. Information only. Set the JP2 jumper
in the backup position (pins 2 and 3)
to allow the server to boot from the
backup UEFI.
W.3048006 [W.3048006] UEFI has booted
from the backup flash bank due
to an Automatic Boot Recovery
(ABR) event.
Automated Boot Recovery,
Booting Backup UEFI Image.
1. Run the Setup utility (see “Using
the Setup utility” on page 115).
Select Load Default Settings and
save the settings.
2. Recover the server firmware.
S.3050007 [S.3050007] A firmware fault
has been detected in the UEFI
image.
Internal UEFI Firmware Fault
Detected, System halted.
1. Check the IBM support website
for an applicable retain tip or
firmware update that applies to
this error.
2. Recover the server firmware.
W.305000A [W.305000A] An invalid date
and time have been detected.
RTC Date and Time Incorrect.
1. Run the Setup utility (see “Using
the Setup utility” on page 115).
Select Load Default Settings and
save the settings.
2. Reseat the battery.
3. Replace the battery.
Chapter 4. Troubleshooting 169
