Table 1. Server features and specifications (continued)
Video controller (integrated into
IMM2):
v Matrox G200eR2
– SVGA compatible video
controller
– DDR2 250 MHz SDRAM video
memory controller
– One analog video port (rear)
– Video memory 16MB is not
expandable in this system
– Avocent Digital Video
Compression
Note: The maximum video
resolution is 1600 x 1200 at 75 Hz.
Electrical input:
v Sine-wave input (50 - 60 Hz)
required
v Input voltage automatically
selected
v Input voltage low range:
– Minimum: 100V ac
– Maximum: 127 V ac
v Input voltage high range:
– Minimum: 200 V ac
– Maximum: 240 V ac
v Input kilovolt-amperes (kVA),
approximately:
– Minimum: 0.12 kVA
– Maximum: 0.9kVA
Acoustical noise emissions:
v Non-redundant power system, Idle
: 5.5 bels, operating :5.8 bels
v Redundant power system, Idle: 6.0
bels, operating: 6.3 bels
Chassis
v 4U standing and rack mountable
mechanical
v Physical dimensions: 425 mm
(Height) x 176 mm (Width) x 635
mm (Depth)
v Weight approximately: 29.7 kg
(65.43 lb) when fully configured or
20 kg (42 lb) minimum
Note:
v Power supplies in the server must be with the same power rating or wattage.
v Legacy 5V PCI adapters are not supported.
v When NVIDIA Quadro 600 graphics Adapter is supported, the max memory
can’t exceed 128GB.
v Graphic Card (VGA Card in SPP list) can only be installed for PCI Slot 4 with
Full-Height bracket. It might be performance limited if VGA Card installed due
to the elec. link is x8.
v Power consumption and heat output vary depending on the number and type of
optional features installed and the power-management optional features in use.
v The sound levels were measured in controlled acoustical environments according
to the procedures specified by ISO 7779 and are reported in accordance with ISO
9296. Actual sound-pressure levels in a given location might exceed the average
values stated because of room reflections and other nearby noise sources. The
noise emission level stated in the declared (upper limit) sound-power level for a
random sample of system.
v When more than 2 PCI-e adapters have been installed on the system, it is
necessary to follow the fan configuration instruction as the table below.
Table 2. Fan configuration instruction
Fans Conditions
2 and Rear
fan
Standard for all systems
3
1. When the second microprocessor is populated, the fan is included in the
second microprocessor kit, P/N: 00D2581 ~ 00D2589. Or
2. When more than 2 PCI-e adapters have been installed on the system, the
fan (P/N: 00D2593) must be populated separately.
1 Optional redundant fan (P/N: 00D2593)
Attention: 16 GB 1.5V / 32 GB 1.35V DIMMs are installed, fan 1 must also
be populated.
8 System x3300 M4 Type 7382: Installation and Service Guide
