RAID cache
card connector
RAID cache
card
Retention
bracket
Retention
tab
Adapter
11. Gently press down on the center of the cache card until it clicks into place on
the connector and is firmly seated.
12. Route the battery cable or flash power module cable along the side of the
chassis and through the SAS cable guide.
Chapter 2. Installing optional devices 85
