IBM System x3750 M4 Type 8722 - System-Board External Connectors

System-board external connectors
The following illustration shows the external input/output connectors on the
system board.
USB 5 (top)
Ethernet 1
Ethernet 2
Serial
connector
Video
connector
Systems-
management
Ethernet
connector
USB 6 (bottom)
Chapter 2. Installing optional devices 27
