Removing a USB embedded hypervisor flash device
To remove a USB embedded hypervisor flash device, complete the following steps:
1. Read the safety information that begins on page “Safety” on page vii and
“Installation guidelines” on page 33.
2. Turn off the server (see “Turning off the server” on page 21) and all attached
peripheral devices. Disconnect all power cords; then, disconnect all external
cables as necessary to replace the device.
3. Remove the top cover (see “Removing the server top cover” on page 206).
4. If any adapters are installed in the PCI riser-card assembly, disconnect any
cables that are connected to the adapters.
5. Remove the PCIe riser-card assembly (see “Removing a PCI riser-card
assembly” on page 258).
6. Locate the USB embedded hypervisor flash device connector on the system
board.
7. Slide the lockbar on the USB flash device connector down to the unlocked
position and pull the USB flash device out of the connector.
Lockbar
USB Hypervisor key
8. If you are instructed to return the flash device, follow all packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
236 System x3750 M4 Types 8722 and 8733: Installation and Service Guide
