PCIe
slot 8
PCIe
slot 7
10 Gb
Ethernet
adapter
connector
PCI riser
card
connector
RAID
cache card
connector
Power interposer
card and
microprocessor/
memory tray
connectors
Microprocessor 1
Microprocessor 2
DIMM 1 - 6
PCIe
slot 6
PCIe
slot 5
PCIe
slot 4
DIMMs 7 - 18
DIMMs 19 - 24
Power supply
connector
USB 4
connector
(hypervisor)
USB 3 connector
(hypervisor)
Optional microprocessor and memory expansion tray
The following illustration shows the connectors and LEDs on the optional
microprocessor and memory expansion tray.
Tray handle
Memory tray
DIMMs
25-30
DIMMs
31-42
DIMMs
43-48
Microprocessor 3
Microprocessor 4
Tray handle
32 System x3750 M4 Types 8722 and 8733: Installation and Service Guide
