Replacing a USB embedded hypervisor flash device
To install a USB hypervisor flash device, complete the following steps:
1. Read the safety information that begins on page “Safety” on page vii and
“Installation guidelines” on page 33.
2. Align the USB flash device with the connector on the system board and push it
into the connector until it is firmly seated.
3. Slide the lockbar up to the locked position until the lockbar is seated firmly.
Lockbar
USB Hypervisor key
4. Reinstall the PCIe riser-card assembly (see “Replacing a PCI riser-card
assembly” on page 259).
5. Reconnect the cables to the adapters, if any were installed in the PCI riser-card.
6. Reconnect the power cord and any cables that you removed.
7. Install the cover (see “Replacing the server top cover” on page 207).
8. Slide the server into the rack.
9. Turn on the peripheral devices and the server.
Chapter 6. Removing and replacing components 237
