Table 1. Server features and specifications (continued)
Optional SATA optical drives:
v Optional DVD-ROM Blu-Ray
(cable comes mounted to the
optical drive bracket in the server)
Hot-swap fans:
The server comes standard with six
dual-motor, counter-rotating,
speed-controlled hot-swap fans for
N+N redundancy.
PCI expansion slots (depending on
your model):
v Five x8 low-profile, PCIe Gen3
adapter slots on the system board
v Three x8 (x16 mechanical) PCIe
Gen3 full-height, half-length
adapter slots on the optional PCI
riser card
Note: The second microprocessor
must be installed on the system
board for the server to support PCIe
slots 4 and 5 on the system board
and the optional PCIe riser card.
Integrated functions:
v Integrated management module II
(IMM2), which provides service
processor control and monitoring
functions, video controller, and
remote keyboard, video, mouse,
and remote hard disk drive
capabilities
v Onboard Emulex BE3 dual port 1
Gb Ethernet controller with iSCSI,
vNIC, TCP/IP Offload Engine
(TOE), Fiber Channel over Ethernet
(FCoE), and Wake on LAN support
Note: The Ethernet controller can
provide up to 10 Gb capability
when you install an optional
Ethernet adapters.
v Onboard LSI 2208 SAS/SATA
RAID controller with support for
RAID levels 0, 1, and 10 and an
optional cache card socket. In
addition, the optional RAID cache
cards and Features on Demand
(FoD) software RAID can provide
additional RAID levels support.
v Light path diagnostics
v Six Universal Serial Bus (USB) 2.0
ports:
– Two on the front of the server
– Two on the rear of the server
– Two internal connectors on the
system board
v Two 1 Gb Ethernet ports on the
system board and two additional
ports when the optional IBM
Dual-port 10 Gb-T (copper)
Ethernet Adapter or the optional
IBM Dual-port 10 Gb SFP+ (fibre)
Ethernet Adapter is installed
v One systems-management RJ-45
connector on the rear to connect to
a systems-management network.
This connector is dedicated to the
IMM v2 functions and runs at 1
Gb speeed.
v One serial port
Power supply:
v The server comes standard with
one 900-watt or one 1400-watt
power supply (depending on the
model).
v Maximum of two 900-watt (110 or
220 V ac auto-sensing) or two
1400-watt ac (110 or 220 V ac
auto-sensing) hot-swap power
supplies.
v Two 1400-watt hot-swap power
supplies fed from a 220 V input
source provides N+N redundancy
support for a full configurations.
v Two 900-watt or two 1400-watt
hot-swap power supplies fed from
a 110 V input source provides
N+N redundancy support for
limited configurations.
Note: The optional IBM Power
Interposer for Redundant Power
option or the optional IBM
Microprocessor and Memory
Expansion Tray must be installed to
support two power supplies.
Video controller (integrated into the
IMM2):
v Matrox G200eR core (two analog
ports: one front and one rear that
can be connected at the same time)
Note: The maximum video
resolution is 1600 x 1200 at 75 Hz
(UXGA), with support for 1680 x
1050 (WSXGA+) wide screen
resolution.
– DDR3 528 MHz SDRAM video
memory controller
– Avocent Digital Video
Compression
– Video memory is not
expandable
Chapter 1. The System x3750 M4 Types 8722 and 8733 server 7
