Force NMI
button
CMOS
battery
1. Follow any special handling and installation instructions that come with the
replacement battery.
2. Insert the new battery:
a. Position the battery so that the positive (+) symbol is facing you.
b. Place the battery into its socket, and press the battery press the battery
toward the housing until it clicks into place. Make sure that the battery clip
holds the battery securely.
3. Reinstall the PCI riser card (see “Installing a PCIe riser-card assembly” on page
65) and reconnect the cables to the adapters.
4. Install the cover (see “Replacing the server top cover” on page 207).
5. Slide the server into the rack.
Chapter 6. Removing and replacing components 257
