Table 16. Supported adapters, slot in which to install the adapters, and information about the adapters. (continued)
Name of adapter
Suggested slot
installation sequence Notes
ServeRAID M5120
SAS/SATA Controller for
IBM System x
PCIe slots 1, 2, 3, 4,
5, 6, 7, and 8
v Provides base RAID levels 0, 1, 5, 10, and 50 (This adapter
comes with a cache card installed):
– With the ServeRAID M5100 Series RAID 6 Upgrade for
IBM System x (Features On Demand software RAID)
enabled on this adapter, you also get RAID level 6 and 60
support.
v You can also install the following RAID cache cards on this
adapter for RAID levels 5 and 50 support:
– ServeRAID M5100 Series 512 MB Cache/RAID 5 Upgrade
for IBM System x
– ServeRAID M5100 Series 512 MB Flash/RAID 5 Upgrade
for IBM System x
– ServeRAID M5100 Series 1 GB Flash/RAID 5 Upgrade for
IBM System x
Note: When any of these three cache cards is installed on
this adapter, you can enable the ServeRAID M5100 Series
RAID 6 Upgrade for IBM System x (Features On Demand
software RAID) to get RAID levels 6 and 60 support.
Optionally, the ServeRAID M5100 Series SSD Caching
Enabler for IBM System x (Features On Demand software
RAID) can be enabled on this adapter to accelerate
solid-state drive RAID devices and reduce processing
overhead that is associated with caching.
v A RAID cache card must be installed on this adapter to run
the MegaRAID firmware.
v The adapter supports external cabling.
v The battery must always be mounted remotely in the server.
IBM 6Gb Performance
Optimized Host Bus
Adapter
PCIe slots 1, 2, 3, 4,
5, 6, 7, and 8
v This solid-state drive controller provides no RAID support.
It helps provide optimized performance for applications that
do not need RAID support.
IBM Dual-port 10 Gb-T
(copper) Ethernet Adapter
Installs in the
optional 10 Gb
Ethernet adapter
connector on the
system board.
Install this adapter in the 10 Gb Ethernet adapter connector on
the system board. For the location of the connector, see
“System-board internal connectors” on page 26.
IBM Dual-port 10 Gb SFP+
(fibre) Ethernet Adapter
Installs in the
optional 10 Gb
Ethernet adapter
connector on the
system board.
Install this adapter in the 10 Gb Ethernet adapter connector on
the system board. For the location of the connector, see
“System-board internal connectors” on page 26.
Chapter 2. Installing optional devices 69
