IBM ThinkPad 760ED Hardware Maintenance Manual

Product Overview (560, 560E)
The following table is an overview of the system features.
Feature Description
Processor 560
 Intel Pentium 100 MHz
 Intel Pentium 120 MHz
 Intel Pentium 133 MHz
560E
 Intel Pentium MMX 150 MHz, L2
cache
 Intel Pentium MMX 166 MHz, L2
cache
Bus Architecture PCI Bus
Memory
(Standard)
560
 8MB (on the system board)
560E
 16MB (on the system board)
Memory (Option) 560
 8MB, 16MB, 32MB DIMM card
(max. 40MB)
560E
 8MB, 16MB, 32MB, 64MB DIMM
card (max. 80MB)
CMOS RAM 114 bytes
VGA Video 560
 11.3-inch, 256 colors, 800×600
pixel DSTN color LCD
 12.1-inch, 64K colors, 800×600
pixel TFT color LCD
560E
 11.3-inch, 64k colors 800×600
pixel DSTN color LCD
 12.1-inch, 256K colors, 800×600
pixel TFT color LCD
Diskette Drive
(External)
 1.44MB (2-mode), 3.5-inch
 1.44MB (3-mode), 3.5-inch, for
Japan
Hard Disk Drive 560
 810MB, 2.5-inch, IDE interface
 1.08GB, 2.5-inch, IDE interface
 2.1GB, 2.5-inch, IDE interface
560E
 2.1GB, 2.5-inch, IDE interface
I/O Port  Headphone
 Microphone
 Port replicator
154 IBM Mobile Systems HMM
