1150 DC/DC Card
 Battery Pack (1010)
 UltraBay II Device or 2nd Battery Pack (1020)
 Keyboard Unit (1060)
 Hinge Cover and Center Cover (1070)
 Eject Lever and Power Switch (1080)
 LCD Unit (1090)
 Standby Battery (1100)
 Upper Shield (1110)
Pull the pullers on the card when removing the card in step
.6/.
Step Size (Quantity) Color Torque
.2/ M2.5 x 6 mm, Nylon
(1)
Black 4 kgcm
.3/ Hex head (2) Self-tapping
screw
4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
592 IBM Mobile Systems HMM
