1040 CD-ROM/FDD Assembly
 Battery Pack (1010)
 Keyboard Unit (1030)
Note: Be careful that the computer does not fall backward
when the CD-ROM/FDD assembly is removed.
Models 380, 380D, 385, and 385D
Step Size (Quantity) Torque
.1/ M 2.5 x 6mm, Nylon (1) 4 kgcm
.2/ M 2.5 x 6mm (1) 4 kgcm
.4/ M 2.5 x 6mm, Special head (1) 3 kgcm
.5/ M 2.5 x 8mm, Nylon (2) 3 kgcm
.6/ M 2.5 x 6mm (1) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
ThinkPad 380, 385 (2635) 63
