IBM ThinkPad 760ED Hardware Maintenance Manual

Model 760XL or 760XD
Feature Description
Processor  760XL/760XD
– Intel MMX Pentium 166MHz
with 256KB L2 Cache
Bus architecture  PCI bus
 VESA local bus for video
subsystem
Memory
(standard)
 760XL
– 16MB
 760XD
– 32MB (16MB on the system
board and 16MB as DIMM)
Memory (option)  8 MB, 16MB, and 32MB DIMM
CMOS RAM 114 bytes + 4 kilobytes
VGA video  760XD
– 12.1-inch, 64K colors,
1024×768 pixel XGA TFT
color LCD
 760XL
– 12.1-inch, 64K colors,
800×600 pixel SVGA TFT
color LCD
Diskette drive
(removable)
 720KB, 1.2MB, 1.44MB, 2.88MB
(4-mode), 3.5-inch
 720KB, 1.2MB, 1.44MB (3-mode),
3.5-inch
Hard disk drive
(removable)
 760XD
– 3.0GB 2.5-inch
 760XL
– 2.1GB 2.5-inch
CD-ROM
(removable)
 760XD
– 5-inch, 8x speed, IDE
interface
Audio function  760XD
– DSP card
 760XL
– ESS card
Infrared transfer  Two IR ports
 IrDA 1.0
 ASK
 1.15 million bps
PCMCIA/cardbus  One Type-III
or two Type-II
ThinkPad 760 (9546, 9547) 245
