Icon Meaning
.1/ Speaker
.2/ Remaining battery
.3/ (left) Secondary battery status
.3/ (right) Main battery status
.4/ Diskette drive in-use
.5/ Hard disk in-use
.6/ Numeric lock
.7/ Caps lock
.8/ Scroll lock
Running the Diagnostics
Use either the TrackPoint III or the cursor-moving keys to
interact with the tests. The Enter key works the same as
selecting the OK icon to reply OK.
The following are required:
FDD:
Erasable 2HD diskette
Parallel:
Wrap plug (P/N 72X8546)
Serial:
Wrap plug (P/N 72X8546)
PCMCIA:
PC Test Card (P/N 35G4703)
CDROM:
Any CD (data CD is recommended)
DVD:
Any CD (don't use DVD disc, but use data
CD)
USB:
USB-Parallel Wrap Cable (P/N 05K2580)
ThinkPad 770 (9548, 9549)
563
