Symptom / Error FRU / Action in Sequence
I9990301
I9990302
I9990305
I9990301: Hard disk
error.
I9990302: Invalid hard
disk boot record.
I9990305: No bootable
device.
1. Check that the
operating system is
installed in the HDD.
If not, install the
operating system.
2. Reseat the boot
device.
3. Check the startup
sequence for the
correct boot device.
4. Check that the
operating system has
no failure and is
installed correctly.
I9990303
(Bank–2 flash ROM check
sum error.)
System board
Other codes, not in this
list
Go to “Undetermined
Problems” on page 51.
Diagnostic Error Codes
A detected error is shown as in the following example:
Large X on the left side of the device icon.
Device ID (three digit)
Error code (two digit)
FRU code (four digit)
The device ID and error code are used to indicate the
detail portion of the FRU that caused the error. If
replacing a FRU does not correct the problem, see the
device ID or error code from the previous failure. If they
have changed, the cause might be because the new FRU
is detective or that the FRU was incorrectly installed.
Device ID: If an error is detected by the diagnostic
tests, a three-digits device ID is displayed. The device ID
indicates suspected device.
Icon Device
ID
Suspected Device
001 System board
003 Keyboard
007 Math coprocessor
086 Pointing device
002 Memory
ThinkPad 380, 385 (2635) 43
