2050 Hinge and LCD Latch
 Battery Pack (1010)
 UltraBay II Device or 2nd Battery Pack (1020)
 Keyboard Unit (1060)
 Hinge Cover and Center Cover (1070)
 LCD Unit (1090)
 LCD Front Cover (2010)
 Inverter Card (2030)
Attention
Make sure you use the correct screw when replacing.
A wrong-size screw will damage the LCD panel.
When replacing:
Make sure the connector is not loosen.
Step Size (Quantity) Color Torque
.1/ M2.5 x 4 mm (2) Yellow 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
606 IBM Mobile Systems HMM
