1090 Upper Shield Case
 Battery Pack (1010)
 DIMM Cover (1020)
 Keyboard Unit (1030)
 CD-ROM/FDD Assembly (1040)
 LCD Unit (1070)
 Hard Disk Drive (1060)
 System Board Assembly (1080)
Step Size (Quantity) Torque
.1/ M 2.5 x 6mm (2) 4 kgcm
.2/ M 2.5 x 6mm, Special head (1) 4 kgcm
.3/ M 2.5 x 8mm (1) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
ThinkPad 380, 385 (2635) 83
