2010 Palm Rest
 Diskette Drive or CD-ROM Drive (1020)
 Battery Pack (1030)
 Hard Disk Drive (1040)
 Top Cover (1060)
 Keyboard Unit (1070)
.1/Turn the keyboard upside down.
.4/Turn the keyboard right-side up.
Step Size (quantity) Torque
.2/ M2.5 x 5 mm, flathead (4) 3 kgcm
.3/ M2.5 x 4 mm (6) 3 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
ThinkPad 765D (9546), 765L (9547) 487
