1060 Top Cover
 Diskette Drive or CD-ROM Drive (1020)
 Battery Pack (1030)
 Hard Disk Drive (1040)
When replacing, be careful not to damage the resume
switch shown in the figure.
Step Size (quantity) Torque
.2/ M2 x 6 mm, Nylon (2) 3 kgcm
.3/ M2.5 x 8 mm, flathead (2) 3 kgcm
.4/ M2.5 x 6 mm, Nylon (1) 3 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
ThinkPad 765D (9546), 765L (9547) 463
