1080 Hard Disk Drive
Attention
Do not drop or apply any shock to the hard disk
drive. The hard disk drive is sensitive to physical
shock. Incorrect handling can cause damage and
permanent loss of data on the hard disk. Before
removing the hard disk drive, have the user make a
backup copy of all the information on the hard disk.
Never remove the hard disk drive while the system is
operating or is in suspend mode. Remove the hard
disk drive exactly as shown in the figure. Do not
apply any extra force to the hard disk drive when
removing it.
 Battery Pack (1030)
 Keyboard Unit (1050)
Step Length (Quantity) Torque
.1/ 7 mm, Nylon (1) 4.0 kgcm
.5/ 3 mm (2) 3.0 kgcm
Note: Make sure you use the correct screw and tighten it to
the torque specified. Do not use the screw that you removed,
use a new screw.
ThinkPad 560, 560E (2640) 169
