1060 Upper Cover
 Port Replicator (1010)
 Option Card Cover and Option Card (1020)
 UltraBay II (1040)
 Device Space Bay Frame (1050)
Important
Make sure all power cords are unplugged before
removing covers.
Step Length (Quantity) Memo
.1/ M 3 x 6 mm (2)
.2/ M 3 x 8 mm (1) Flat head (black)
.3/ M 3 x 4 mm (1)
.4/ M 3 x 6 mm (2)
.6/ M 3 x 8 mm (2) Self-tapping screw
.7/ M 3 x 8 mm (2) Black
.8/ M 3 x 8 mm (2) Black
.9/ M 3 x 8 mm (3) Self-tapping screw
662 IBM Mobile Systems HMM
