2040 LCD Cable and Hinges
 DIMM (If Installed) (1020)
 Battery Pack (1030)
 Keyboard Unit (1050)
 LCD Assembly (1060)
 LCD Front Cover (2010)
 LCD Panel (2020)
 Inverter Card (DSTN only)(1140)
DSTN
 .1/.2/: LCD cable
 .3/.4/: Hinges
When replacing: see the following figure.
Step Size (Quantity) Torque
.1/ M 2.5 x 6 mm, flathead (2) 3.0 kgcm
.3/ M 2.5 x 6 mm (3)
flathead
3.0 kgcm
Note: Make sure you use the correct screw and tighten it to
the torque specified. Do not use the screw that you removed,
use a new screw.
ThinkPad 560, 560E (2640) 181
