1180 PC Card Slot
 Battery Pack (1010)
 UltraBay II Device or 2nd Battery Pack (1020)
 Keyboard Unit (1060)
 Hinge Cover and Center Cover (1070)
 Eject Lever and Power Switch (1080)
 LCD Unit (1090)
 Standby Battery (1100)
 Upper Shield (1110)
 Video Card (1130)
 Modem Card (1140)
Note: When removing the PC Card slot, make sure that
the PC Card eject buttons do not pop out.
Step Size (Quantity) Color Torque
.1/ M2 x 14 mm (2) Yellow 2.5
kgcm
.2/ M2.5 x 4 mm, Nylon
(2)
Yellow 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
598 IBM Mobile Systems HMM
