1100 System Board Assembly
 Diskette Drive/CD-ROM Drive (1020)
 Battery Pack (1030)
 Hard Disk Drive (1040)
 Top Cover (1060)
 Keyboard Unit (1070)
 LCD Unit (1080)
 Rear IR (1090)
Note: In step 1, gently pushing the shaded area
1
, lift
the switch cover halfway up
2
, as shown. Then
pull the switch lever out to remove
3
.
262 IBM Mobile Systems HMM
To Next Page
