Product Overview (760)
The following table shows an overview of the system
features:
Model 760C or 760CD
Feature Description
Processor  Intel Pentium 90 MHz with
256KB L2 Cache
 Intel Pentium 120 MHz with
256KB L2 Cache
Bus architecture  AT bus
 VESA local bus for video
subsystem
Memory
(standard)
8MB (on the system board)
Memory (option)  4MB, 8MB, 16MB, DIMM (max.
40MB)
 DIMM adapter
CMOS RAM 114 bytes
VGA video  12.1-inch, 64K colors, 800×600
pixel TFT color LCD
 10.4-inch, 64K colors, 800×600
pixel TFT color LCD
Diskette drive
(removable)
 720KB, 1.2MB, 1.44MB, 2.88MB
(4-mode), 3.5-inch
 720KB, 1.2MB, 1.44MB (3-mode),
3.5-inch
Hard disk drive
(removable)
 760C
– 360MB, 2.5-inch
– 720MB, 2.5-inch
 760CD
– 810MB, 2.5-inch
– 1200MB, 2.5-inch
Enhanced video
card
 760CD
– Video accelerator
– Video capture and overlay
– Video composite in/out
– MPEG hardware decoding
– MPEG2
CD-ROM
(removable)
 760CD
– 5-inch, quadruple speed, IDE
interface
DSP card  Audio function
 Fax/modem function
 Telephony function
 MWave function
Infrared transfer  Two IR ports
 IrDA 1.0
 ASK
 1.15 million bps
PCMCIA  One Type-III
or two Type-II
ThinkPad 760 (9546, 9547) 241
