IBM ThinkPad 760ED Hardware Maintenance Manual

Model 760E or 760ED
Feature Description
Processor  Intel Pentium 120 MHz with
256KB L2 Cache
 Intel Pentium 133 MHz with
256KB L2 Cache
 Intel Pentium 150 MHz with
256KB L2 Cache
Bus architecture  PCI bus
 VESA local bus for video
subsystem
Memory
(standard)
8MB or 16MB (on the system board)
Memory (option)  8MB, 16MB, 32MB, DIMM (max.
72MB or 80MB)
 DIMM adapter
CMOS RAM 114 bytes + 4 kilobytes
VGA video  12.1-inch, 64K colors, 800×600
pixel TFT color LCD
 12.1-inch, 64K colors, 1024×768
pixel TFT color LCD
Diskette drive
(removable)
 720KB, 1.2MB, 1.44MB, 2.88MB
(4-mode), 3.5-inch
 720KB, 1.2MB, 1.44MB (3-mode),
3.5-inch
Hard disk drive
(removable)
 810MB, 2.5-inch
 1.08GB, 2.5-inch
 1.2GB, 2.5-inch
 1.35GB, 2.5-inch
 2.1GB, 2.5-inch
Enhanced video
card
 760ED (enhanced model)
– Video accelerator
– Video capture and overlay
– Video composite in/out
– S-video in
– MPEG hardware decoding
– MPEG2
CD-ROM
(removable)
 760ED
– 5-inch, 4X, 6X, or 8X speed,
IDE interface
DSP card  Audio function
 Fax/modem function
 Telephony function
 MWave function
Infrared transfer  Two IR ports
 IrDA 1.0
 ASK
 1.15 million bps
PCMCIA/cardbus  One Type-III
or two Type-II
242 IBM Mobile Systems HMM
