Symptom or Error FRUs of the SelectaDock

Sequence of Actions

6XX 1. Before changing any

devices, run the

diagnostic test.

2. FDD external

attachment kit.

3. Diskette drive

assembly.

4. Riser card.

11XX, 12XX 1. Serial devices.

2. Communication cable.

3. Riser card.

17XX 1. Hard disk drive

(2.5-inch ThinkPad

hard disk drive).

2. Main card.

24XX 1. Main card.

2. Riser card.

860X 1. Mouse.

2. External keyboard.

3. Riser card.

I9990301, I9990302

I9990305

See the hardware

maintenance manual for

the computer.

Not shown above 1. See the hardware

maintenance manual

for the computer.

2. See “Undetermined

Problems” on

page 653.

642 IBM Mobile Systems HMM
