94 IBM System x3850 X6 and x3950 X6 Planning and Implementation Guide
For more information, see the list of IBM Redbooks Product Guides in the Networking
adapters category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=networkadapters
3.16 Storage host bus adapters
The following table lists storage HBAs supported by the x3850 X6 and x3950 X6 servers. The
maximum quantity listed is for configurations with all processors and I/O Books installed.
Table 3-23 Storage adapters options
For more information, see the list of IBM Redbooks Product Guides in the Host bus adapters
category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=hba
InfiniBand
00D9550 A3PN Mellanox ConnectX-3 40GbE / FDR IB VPI Adapter No 9 / 18
a. Quantities for x3850 X6 / x3950 X6
Part
number
Feature
code
Description Hot-swap
capable
Maximum
supported
a
Part
number
Feature
code
Description Hot-swap
capable
Maximum
supported
x3850 X6
Maximum
supported
x3950 X6
Fibre Channel - 16 Gb
81Y1655 A2W5 Emulex 16Gb FC Single-port HBA No 9 18
81Y1662 A2W6 Emulex 16Gb FC Dual-port HBA No 9 18
81Y1668 A2XU Brocade 16Gb FC Single-port HBA No 9 18
81Y1675 A2XV Brocade 16Gb FC Dual-port HBA No 9 18
00Y3337 A3KW QLogic 16Gb FC Single-port HBA No 9 18
00Y3341 A3KX QLogic 16Gb FC Dual-port HBA No 9 18
Fibre Channel - 8 Gb
42D0485 3580 Emulex 8 Gb FC Single-port HBA No 9 18
42D0494 3581 Emulex 8 Gb FC Dual-port HBA No 9 18
42D0501 3578 QLogic 8 Gb FC Single-port HBA No 9 18
42D0510 3579 QLogic 8 Gb FC Dual-port HBA No 9 18
46M6049 3589 Brocade 8 Gb FC Single-port HBA No 9 18
46M6050 3591 Brocade 8 Gb FC Dual-port HBA No 9 18
SAS
46C9010 A3MV N2125 SAS/SATA HBA No 9 18

IBM X3850 X6 Specifications

General

Chipset	Intel C602J
Network Controller	Integrated quad-port Gigabit Ethernet
Processor	Up to four Intel Xeon E7-4800 v2 series processors or Intel Xeon E7-8800 v2 series processors
Memory	Up to 6 TB of DDR3 ECC Registered DIMMs (RDIMMs) or Load-Reduced DIMMs (LRDIMMs)
Form Factor	4U rack server
Storage	Up to 24x 2.5" hot-swap SAS/SATA HDDs or SSDs
Expansion Slots	Up to 11 PCIe 3.0 slots
Power Supply	Up to four 1400W or 900W hot-swap power supplies
Memory Type	DDR3 RDIMM/LRDIMM
Storage Controller	ServeRAID M5210 SAS/SATA controller
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
