IBM X3850 X6 User Manual

Chapter 3. Product information 95
3.17 GPU adapters and co-processors
The server supports co-processors and graphics processing units (GPUs) that are listed in
Table 3-24. Each is installed in a Full-length I/O Book. No other adapter can be installed in the
Full-length I/O Book. The Full-length I/O Book includes the necessary auxiliary power cables.
The GPUs and coprocessors have server memory minimums and maximums as indicated in
the table.
Table 3-24 GPU adapters and coprocessors
Not available via CTO: These adapters are not available via CTO and cannot be shipped
installed in the server. This is because they are installed in the Full-length I/O Book, which
extends beyond the rear of the chassis (see Figure 3-31 on page 91). These adapters
must be shipped separately from the server.
Part
number
Feature
code
Description Min / Max
system
RAM
Hot-swap
capable
Maximum
supported
x3850 X6
Maximum
supported
x3950 X6
00FP670 A4G4
a
a. Not available via CTO.
Intel Xeon Phi 3120A PCIe x16 for
System x3850/x3950 X6
Min 12 GB No 2 4
00FP671 A5U2
a
NVIDIA Grid K1 PCIe x16 for
System x3850/x3950 X6
32 GB / 1 TB No 2 4
00FP674 A470
a
NVIDIA Grid K2 Actively Cooled PCIe
x16 for System x3850/x3950 X6
16 GB / 1 TB No 2 4
00FP673 A471
a
NVIDIA Tesla K20 Actively Cooled
PCIe x16 for System x3850/x3950 X6
10 GB / 1 TB No 2 4
00FP676 A5FG
a
NVIDIA Tesla K40c PCIe x16 for
System x3850/x3950 X6
24 GB / 1 TB No 2 4
00FP675 A3YU
a
NVIDIA Quadro K4000 PCIe x16 for
System x3850/x3950 X6
6 GB / 1 TB No 2 4
00FP672 A3YV
a
NVIDIA Quadro K6000 PCIe x16 for
System x3850/x3950 X6
24 GB / 1 TB No 2 4

IBM X3850 X6 Specifications

General

Chipset	Intel C602J
Network Controller	Integrated quad-port Gigabit Ethernet
Processor	Up to four Intel Xeon E7-4800 v2 series processors or Intel Xeon E7-8800 v2 series processors
Memory	Up to 6 TB of DDR3 ECC Registered DIMMs (RDIMMs) or Load-Reduced DIMMs (LRDIMMs)
Form Factor	4U rack server
Storage	Up to 24x 2.5" hot-swap SAS/SATA HDDs or SSDs
Expansion Slots	Up to 11 PCIe 3.0 slots
Power Supply	Up to four 1400W or 900W hot-swap power supplies
Memory Type	DDR3 RDIMM/LRDIMM
Storage Controller	ServeRAID M5210 SAS/SATA controller
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
