Chapter 4. Infrastructure planning 125
4.8.2 PDU and line cord options
Some PDUs have attached line cords while others require a line cord to be ordered
separately based on your requirement of Three-phase power or Single-phase power. See
Table 4-7 for PDU, line cord, and phase options for both North America and International
PDUs.
Table 4-7 Power distribution units and line cords
Part
number
Description Line cord
part
number
Phase Volts
(V)
Line cord rating
(Derated)
Line cord plug Number /
Type of
outlets
Switched and Monitored PDUs - North America
46M4002 IBM 1U 9 C19/3 C13
AEM DPI PDU
40K9614 1ph 200V-240V 30A (24A) NEMA L6 30P 9 / C19
3 / C13
40K9615 1ph 200V-240V 60A (48A) IEC 309 2P+G
46M4003 IBM 1U 9 C19/3 C13
AEM 60A 3 Phase
PDU
Attached 3ph 208V 60A (27.7A/ph) IEC 309 3P+G 9 / C19
3 / C13
46M4004 IBM 1U 12 C13 AEM
DPI PDU
40K9614 1ph 200V-240V 30A (24A) NEMA L6 30P 12 / C13
40K9615 1ph 200V-240V 60A (48A) IEC 309 2P+G
46M4005 IBM 1U 12 C13 AEM
60A 3 Phase PDU
Attached 3ph 208V 60A (27.7A/ph) IEC 309 3P+G 12 / C13
46M4167 IBM 1U 9 C19/3 C13
Switched and
Monitored 30A 3
Phase PDU
Attached 3ph 208V 30A (13.85A/ph) NEMA L21-30P 9 / C19
3 / C13
46M4116 IBM 0U 24 C13
Switched and
Monitored 30A PDU
Attached 1ph 200V-240V 30A (24A) NEMA L6 30P 24 / C13
46M4134 IBM 0U 12 C19/12
C13 Switched and
Monitored 50A 3
Phase PDU
Attached 3ph 208V 50A (23.09A/ph) CS8365L 12 / C19
12 / C13
Switched and Monitored PDUs - International
46M4119 IBM 0U 24 C13
Switched and
Monitored 32A PDU
Attached 1ph 220V-240V 32A IEC 309 P+N+G 24 / C13
46M4137 IBM 0U 12 C19/12
C13 Switched and
Monitored 32A 3
Phase PDU
Attached 3ph Y 380V-415V 32A (32A/ph) IEC 309
3P+N+G
12 / C19
12 / C13
46M4002 IBM 1U 9 C19/3 C13
AEM DPI PDU
40K9612 1ph 220V-240V 32A IEC 309 P+N+G 9 / C19
3 / C13
40K9613 1ph 220V-240V 63A IEC 309 P+N+G
40K9617 1ph 230V-240V 32A AUS/NZ 3112
40K9618 1ph 220V 30A KSC 8305
40K9611 3ph Y 380V-415V 32A (32A/ph) IEC 309
3P+N+G
47C2495 3ph Y 380V-415V 16A (16A/ph) IEC 309
3P+N+G

IBM X3850 X6 Specifications

General

Chipset	Intel C602J
Network Controller	Integrated quad-port Gigabit Ethernet
Processor	Up to four Intel Xeon E7-4800 v2 series processors or Intel Xeon E7-8800 v2 series processors
Memory	Up to 6 TB of DDR3 ECC Registered DIMMs (RDIMMs) or Load-Reduced DIMMs (LRDIMMs)
Form Factor	4U rack server
Storage	Up to 24x 2.5" hot-swap SAS/SATA HDDs or SSDs
Expansion Slots	Up to 11 PCIe 3.0 slots
Power Supply	Up to four 1400W or 900W hot-swap power supplies
Memory Type	DDR3 RDIMM/LRDIMM
Storage Controller	ServeRAID M5210 SAS/SATA controller
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
