Chapter 3. Product information 81
3.10.5 IBM High IOPS adapter
The IBM High IOPS SSD PCIe Adapters are high performance SSD storage adapters with
very low latency. Depending on the workload, the High IOPS adapter can deliver throughput
of up to 900,000 IOPS and latency less than 100 microseconds.
Table 3-13 shows available IBM High IOPS adapter options.
Table 3-13 IBM High IOPS adapter options
For more information about the IBM High IOPS adapter, see 2.6.4, “IBM High IOPS adapters”
on page 41.
3.10.6 External disk storage expansion
The server supports attachment to external storage expansion enclosures, such as the
EXP2500 series, by using the ServeRAID M5120 SAS/SATA Controller. The server can also
be attached to supported external storage systems, such as the IBM System Storage
DS3500 series, using a supported HBA.
Table 3-14 lists the supported RAID controller and HBA for external storage connectivity.
Table 3-14 RAID controllers and options for external disk storage expansion
Part
number
Feature
code
Description Maximum
supported
x3850 X6
Maximum
supported
x3950 X6
46C9078 A3J3 IBM 365GB High IOPS MLC Mono Adapter 9 18
46C9081 A3J4 IBM 785GB High IOPS MLC Mono Adapter 9 18
90Y4377 A3DY IBM 1.2TB High IOPS MLC Mono Adapter 9 18
90Y4397 A3DZ IBM 2.4TB High IOPS MLC Duo Adapter 9 18
Part
number
Feature
code
Description Maximum
supported
x3850 X6
Maximum
supported
x3950 X6
81Y4478 A1WX ServeRAID M5120 SAS/SATA Controller 2 5
46C9010 A3MV N2125 SAS/SATA HBA for IBM System x 9 18
Supported hardware upgrades for the M5120
81Y4487 A1J4 ServeRAID M5100 Series 512MB Flash/RAID 5 Upgrade 1 2
81Y4559 A1WY ServeRAID M5100 Series 1GB Flash/RAID 5 Upgrade 1 2
Supported IBM Features on Demand upgrades for the M5120
90Y4318 A2MD ServeRAID M5100 Series SSD Caching Enabler 1
a
a. These M5120 features upgrades require a cache memory upgrade (81Y4487 or 81Y4559).
2
a
90Y4273 A2MC ServeRAID M5100 Series SSD Performance Key 1
a
2
a
81Y4546 A1X3 ServeRAID M5100 Series RAID 6 Upgrade 1
a
2
a

IBM X3850 X6 Specifications

General

Chipset	Intel C602J
Network Controller	Integrated quad-port Gigabit Ethernet
Processor	Up to four Intel Xeon E7-4800 v2 series processors or Intel Xeon E7-8800 v2 series processors
Memory	Up to 6 TB of DDR3 ECC Registered DIMMs (RDIMMs) or Load-Reduced DIMMs (LRDIMMs)
Form Factor	4U rack server
Storage	Up to 24x 2.5" hot-swap SAS/SATA HDDs or SSDs
Expansion Slots	Up to 11 PCIe 3.0 slots
Power Supply	Up to four 1400W or 900W hot-swap power supplies
Memory Type	DDR3 RDIMM/LRDIMM
Storage Controller	ServeRAID M5210 SAS/SATA controller
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
