IBM X3850 X6 User Manual

Chapter 4. Infrastructure planning 127
71762MX IBM Ultra Density
Enterprise PDU C19
PDU+ (WW)
40K9612 1ph 220V-240V 32A IEC 309 P+N+G 9 / C19
3 / C13
40K9613 1ph 220V-240V 63A IEC 309 P+N+G
40K9617 1ph 230V-240V 32A AUS/NZ 3112
40K9618 1ph 220V 30A KSC 8305
40K9611 3ph Y 380V-415V 32A (32A/ph) IEC 309
3P+N+G
47C2495 3ph Y 380V-415V 16A (16A/ph) IEC 309
3P+N+G
39M2816 IBM DPI C13
Enterprise PDU
without line cord
Monitored
40K9612 1ph 220V-240V 32A IEC 309 P+N+G 12 / C13
40K9613 1ph 220V-240V 63A IEC 309 P+N+G
40K9617 1ph 230V-240V 32A AUS/NZ 3112
40K9618 1ph 220V 30A KSC 8305
40K9611 3ph Y 380V-415V 32A (32A/ph) IEC 309
3P+N+G
47C2495 3ph Y 380V-415V 16A (16A/ph) IEC 309
3P+N+G
39Y8941 DPI Single Phase C13
Enterprise PDU
without line cord
40K9612 1ph 220V-240V 32A IEC 309 P+N+G 12 / C13
40K9613 1ph 220V-240V 63A IEC 309 P+N+G
40K9617 1ph 230V-240V 32A AUS/NZ 3112
40K9618 1ph 220V 30A KSC 8305
40K9611 3ph Y 380V-415V 32A (32A/ph) IEC 309
3P+N+G
47C2495 3ph Y 380V-415V 16A (16A/ph) IEC 309
3P+N+G
39Y8948 DPI Single Phase C19
Enterprise PDU
without line cord
40K9612 1ph 220V-240V 32A IEC 309 P+N+G 6 / C19
40K9613 1ph 220V-240V 63A IEC 309 P+N+G
40K9617 1ph 230V-240V 32A AUS/NZ 3112
40K9618 1ph 220V 30A KSC 8305
40K9611 3ph Y 380V-415V 32A (32A/ph) IEC 309
3P+N+G
47C2495 3ph Y 380V-415V 16A (16A/ph) IEC 309
3P+N+G
Front-end PDUs - North America
39Y8938 30 amp/125V
Front-end PDU
Included 1ph 125V 30A (24A) NEMA L5-30P 3 / C19
39Y8939 30 amp/240V
Front-end PDU
Included 1ph 200V-240V 30A (24A) NEMA L6-30P 3 / C19
39Y8940 60 amp Front-end
PDU
Included 1ph 200V-240V 60A (48A) IEC 309 2P+G 3 / C19
Part
number
Description Line cord
part
number
Phase Volts
(V)
Line cord rating
(Derated)
Line cord plug Number /
Type of
outlets

IBM X3850 X6 Specifications

General

Chipset	Intel C602J
Network Controller	Integrated quad-port Gigabit Ethernet
Processor	Up to four Intel Xeon E7-4800 v2 series processors or Intel Xeon E7-8800 v2 series processors
Memory	Up to 6 TB of DDR3 ECC Registered DIMMs (RDIMMs) or Load-Reduced DIMMs (LRDIMMs)
Form Factor	4U rack server
Storage	Up to 24x 2.5" hot-swap SAS/SATA HDDs or SSDs
Expansion Slots	Up to 11 PCIe 3.0 slots
Power Supply	Up to four 1400W or 900W hot-swap power supplies
Memory Type	DDR3 RDIMM/LRDIMM
Storage Controller	ServeRAID M5210 SAS/SATA controller
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
