■ Memory channel selection
8
102
MEMORY OPERATION
The transceiver has 501 memory channels includes 6
scan edge channels (3 pairs), and 2 call channels. In
addition, a total of 5 memory banks (99 memory chan-
nel each), A to E, are available for usage by group, etc.
Memory mode is very useful for quickly changing to
often-used frequencies.
All 503 memory/call channels are tuneable which
means the programmed frequency can be tuned tem-
porarily with [DIAL], etc., in memory mode.
MEMORY
CHANNEL
MEMORY
CHANNEL
NUMBER
CAPABILITY
TRANSFER
TO VFO
OVER-
WRITING
CLEAR
Regular
(split memory)
1–99
(in each
banks)
Independent transmit and receive
frequencies and one mode in each
memory channel.
In addition, tone frequencies can
also be stored for repeater use.
Yes Yes Yes
Scan edges
1A–3B
(common)
One frequency and one mode in
each memory channel as scan
edges for programmed scan.
Yes Yes No
Call channels
(split memory)
C1, C2
(common)
Same as regular channels, but 144
MHz (C1), 430 MHz (C2) band can
be programmed.
Yes Yes No
■ Memory channels
q Push [PBT/M-ch/RIT] momentarily to select the M-
ch/RIT function, if the twin PBT is selected.
•[PBT/M-ch/RIT] indicator (Green) goes out.
w Select the menu
M
-
2
.
e Push [F-4
V/M
] to select memory mode.
r Rotate [M-ch] (inner) control to select the desired
memory channel.
•All memory channels including blank channels can be
selected.
•Rotating [RIT] (outer) control changes the bank.
• [
Y
]/[
Z
] on the microphone also change the channels.
t To return to VFO mode, push [F-4
V/M
] again.
