RECEIVE AND TRANSMIT
4
D Convenient functions for transmit
• Transmit quality monitor (p. 89)
➥ Push [AF(
SET
)], then [F-4
OTH
] to enter the mis-
cellaneous (others) set mode. Select an item with
[F-1
≤
]/[F-2
≥
], then rotate [DIAL] to turn the
monitor function ON and OFF.
• VOX (voice operated transmit) (p. 85)
➥ While “
M
-
3
” is selected, push [F-1
VOX
] to turn
the VOX function ON and OFF.
• “ ” appears when the VOX function is set to ON.
➥ While “
M
- 3
” is selected, push [F-1
VOX
] for 1
sec. to enter the VOX set mode.
•Push [F-1
≤
]/[F-2
≥
] to select an item.
•Rotate [DIAL] to set the value/conditions.
• Speech compressor (p. 89)
➥ While “
M
- 3
” is selected, push [F-2
COM
] to turn
the speech compressor ON and OFF.
• “”appears when the speech compressor is set to
ON.
➥ While “
M
- 3
” is selected, push [F-2
COM
] for 1
sec. to enter the compression level set mode.
•Rotate [DIAL] to adjust the compression level.
•Push and hold [MENU/GRP] for 1 sec. once or twice
to select the menu group
M
.
•Push [MENU/GRP] momentarily one or more times
to select the menu
M
- 3
.
D
About 5 MHz band operation (USA version only)
Operation on the 5 MHz band is allowed on 5 discrete
frequencies and must adhere to the following:
• USB mode
• Maximum of 50 watts ERP
(Effective Radiated Power)
• 2.8 kHz bandwidth
It is the operator’s responsibility to set all controls so
that the transmission in this band meets the stringent
conditions under which we may use these frequencies.
NOTE: We recommend that you store these fre-
quencies, mode and filter settings into the memory
channel for easy recall.
*The channel center frequencies that are specified
by the FCC, show the center frequency of their
passband. However, the IC-7000 displays carrier
point frequency, so set 1.5 kHz below from FCC
channel center frequency.
IC-7000 Tuning FCC Channel
Frequency* Center Frequency*
5.33050 MHz 5.33200 MHz
5.34650 MHz 5.34800 MHz
5.36650 MHz 5.36800 MHz
5.37150 MHz 5.37300 MHz
5.40350 MHz 5.40500 MHz
To assist you in operating the 5 MHz band correctly
within the rules specified by the FCC, transmission
is impossible on any 5 MHz band frequency other
than the 5 frequencies indicated in the table above.

Icom IC-7000 Specifications

General

Input voltage	13.8 V
Microphone included	Yes
Product type	Portable CB radio
Product color	Black
Housing material	-
Frequency range	0.5 - 455000 MHz
Channels quantity	503 channels

Weight and Dimensions

Depth	180 mm
Width	167 mm
Height	58 mm
