Icom IC-7000 Instruction Manual

63
4
RECEIVE AND TRANSMIT
■ Repeater operation
A repeater amplifies received signals and retransmits
them at a different frequency. When using a repeater,
the transmit frequency is shifted from the receive fre-
quency by an offset frequency. A repeater can be ac-
cessed using split frequency operation with the shift
frequency set to the repeater’s offset frequency.
For accessing a repeater which requires a repeater
tone, set the repeater tone frequency in the FM tone
set mode as described on the next page.
• To set the transceiver for repeater operation, follow
the steps q to e to select VFO mode, desired band,
FM mode.
q Push [F-4
V/M
] to select VFO mode.
w Push [
Y
(
BAND
)]/[
Z
(
BAND
)] to select the desired
band or push a band key on the HM-151.
e Push [MODE] momentarily or push and hold for 1
sec. to select FM mode.
•After FM, WFM or AM mode is selected, push [MODE]
for 1 sec. to select from FM, WFM and AM modes.
r Rotate [DIAL] to set the receive frequency (repeater
output frequency).
t Select
M
- 3
.
y Push [F-2
DUP
] once or twice to set the offset di-
rection.
• “ ” or “ ” appears.
•The default repeater offsets are the standard values of
0.1000 MHz for HF, 0.500 MHz for 50MHz, 0.600 MHz
for 144 MHz, and 5.000 MHz for 430 MHz. The offset
can be adjusted in set mode. (p. 132)
•The transmit frequency can be monitored while pushing
[F-4
XFC
] in the
M
- 1
display
.
u Push [F-3
TON
] to turn the repeater tone ON.
• “”appears.
•The tone frequency can be set in the FM tone set mode
as described on the next page.
i Communicate in the usual manner.
•Push and hold [PTT] to transmit; release [PTT] to re-
ceive.
•Push and hold [MENU/GRP] for 1 sec. once or twice to
select the menu group
M
.
•Push [MENU/GRP] momentarily one or more times to
select the menu
M
- 2
.
Shifted frequency
and mode appear.
“DUP–” or “DUP+”
appears.
“TONE” appears.
[DIAL][MENU/GRP] [F-2] [F-3]
This function allows you to set repeater operation by
pushing one key.
➥ To set the transceiver for repeater operation using
the one-touch repeater function, follow the steps q
to t as above, then push and hold [F-2
DUP
] for
1sec.
•Push [F-2
DUP
] for 1 sec. again to exit the repeater op-
erating condition
.
Set the offset shift direction and frequency in ad-
vance (p. 132) as well as the tone frequency (see
p. 64).
[F-2]
D One-touch repeater function

Icom IC-7000 Specifications

General

Input voltage	13.8 V
Microphone included	Yes
Product type	Portable CB radio
Product color	Black
Housing material	-
Frequency range	0.5 - 455000 MHz
Channels quantity	503 channels

Weight and Dimensions

Depth	180 mm
Width	167 mm
Height	58 mm
