41
4
RECEIVE AND TRANSMIT
■ Operating CW
q Connect a paddle or straight key as on page 22.
w Push [
Y
(
BAND
)]/[
Z
(
BAND
)] to select the desired
band or push a band key on the HM-151.
e Push [MODE] momentarily to select CW mode.
•After CW mode is selected, push [MODE] for 1 sec. to
toggle between CW and CW-R modes.
r Rotate [DIAL] to tune in a desired signal with the
desired tone frequency.
t Rotate [AF] to set audio to a comfortable listening
level.
y Set CW break-in operation as semi break-in, full
break-in or OFF.
•Push [F-1
BRK
] one or more times to select the CW
break-in operation.
• “,” “,” and “OFF (no indication)” appears.
➧ BK-IN: semi break-in
➧ F-BK : full break-in
➧ OFF : no break-in (ACC socket connection is neces-
sary as shown on page 22.)
u Set the CW delay time when semi break-in opera-
tion is selected.
•Push [F-1
BRK
] for 1 sec. to enter the break-in delay
time set mode.
•Rotate [DIAL] to set the desired delay time.
i Set CW setting in the keyer set mode (
S
-
1
).
•Push [F-2
KEY
], [
Z
(
MENU
/
GRP
)], then [F-4
SET
] to
enter the keyer set mode. (p. 49)
o Keying to transmit, use the electric keyer or paddle
to send your CW signals.
• [TX] indicator lights red.
• The Po meter indicates transmitted CW signal strength.
!0 Stop keying to return to receive.
•Push and hold [MENU/GRP] for 1 sec. once or twice
to select the menu group
S
.
•Push [MENU/GRP] momentarily one or more times to
select the menu
S
-
1
.
•Push and hold [MENU/GRP] for 1 sec. once or twice
to select the menu group
M
.
•Push [MENU/GRP] momentarily one or more times to
select the menu
M
-
3
.
