RECEIVE AND TRANSMIT
4
D Storing a non standard repeater
q Turn the auto repeater function OFF in the miscel-
laneous (others) set mode. (p. 133)
w Push [MODE] to select FM mode.
e Select
M
- 2
.
r Push [F-4
V/M
] to select VFO mode.
t Select
M
- 1
, then push [F-2
A/B
] to select VFO A.
y Rotate [DIAL] to set the receive frequency (re-
peater output frequency).
u Push [F-2
A/B
] to select VFO B.
i Rotate [DIAL] to set the transmit frequency (re-
peater input frequency).
o Push [F-2
A/B
] to select VFO A.
!0 Push [F-1
SPL
] to turn the split function ON.
• “ ” appears.
!1 Select
M
- 3
, then push [F-3
TON
] to turn on the
previously set tone encoder ON. (p. 64)
!2 Rotate [M-ch] to select the desired memory chan-
nel.
• “ ” appears when the blank channel is selected.
!3 Select
M
- 2
, then push [F-2
MW
] for 1 sec. to store
the contents in the selected memory channel.
Rotate
Push
push
TON
SPL
push
MW
Set the frequency.
Selected M2, then
Selected M3, then
Set the frequency.
Appears
Appears
Select
Select
Select
•Push and hold [MENU/GRP] for 1 sec. once or twice
to select the menu group
M
.
•Push [MENU/GRP] momentarily one or more times to
select the menu
M
- 2
.
[DIAL][MENU/GRP]
[F-1]
[F-2] [F-3] [F-4]
