Icom IC-7000 Instruction Manual

22
2
INSTALLATION AND CONNECTIONS
2
Rear panel
Paddle
[KEY]
[MICROPHONE]
Straight key
Microphone (HM-103)
Keyer set mode setting
Keyer set mode (p. 49)
4
8
12
[ACC]
123
765
9
10 11
13
For no break-in operation:
Connect an external switch
such as a foot switch; or use
the RTTY SEND terminal for
all bands. (See p. 23)
See p. 50 for connection details:
Paddle operation from [MIC]
connector
.
Normal
Reverse
Bug
Paddle polarity
Normal
MIC U/D keyer (HM-103)
ON
Keyer Type
ELEC-KEY
Paddle polarity
Normal
Keyer Type
Straight
Paddle polarity
Normal
Keyer Type
ELEC-KEY
Paddle polarity
Reverse
Keyer Type
ELEC-KEY
Paddle polarity
Normal
Keyer Type
BUG-KEY
■ Connections for CW

Icom IC-7000 Specifications

General

Input voltage	13.8 V
Microphone included	Yes
Product type	Portable CB radio
Product color	Black
Housing material	-
Frequency range	0.5 - 455000 MHz
Channels quantity	503 channels

Weight and Dimensions

Depth	180 mm
Width	167 mm
Height	58 mm
