BASIC OPERATION
■ When first applying power (CPU resetting)
Before first applying power, make sure all connections
required for your system are complete by referring to
Chapter 2. Then, reset the transceiver using the fol-
lowing procedure.
Resetting CLEARS all programmed contents in
memory channels and returns all initial set mode and
quick set mode contents to their default values.
q Make sure the transceiver power is OFF.
w While pushing [Y] and [Z], push [POWER] to turn
power ON.
•“CLEAR ? OK” appears as shown at right.
e Then push [F-3] for 1 sec to start resetting.
• The internal CPU is reset.
•The display changes to ‘All indication,’ ‘RF power,’ ‘Power
supply voltage’ and ‘Initial frequency and Mode’ as shown
at right.
D M1 display selection
If you can’t figure out how to return to the M1 display:
While pushing [MENU], turn power ON.
■ Initial settings
After resetting the transceiver, set controls and
switches as shown in the diagram below.
Turn power ON, then check the display. If any of the
following indicators appear, turn them OFF as follows:
•Tuning step indicators,
Z
, (SSB, CW or RTTY):
Push [TS].
•MHz tuning step indicator,
Z
, (FM or AM):
Push [TS].
• 1 Hz frequency readout (SSB, CW or RTTY):
Push and hold [TS].
• Memory mode indicator, MEMO:
Use [(F-3)V/M] in the M2 display (p. 75).
• Split indicator, ä:
Use [(F-1)SPL] in the M1 display (p. 75).
