29
4
RECEIVE AND TRANSMIT
D CW operation
q Connect a paddle or straight key as at previous
page.
w Push [(Y)BAND]/[(Z)BAND] to select the desired
band.
e Push [MODE] momentarily to select CW mode.
•After CW mode is selected, push [MODE] for 1 sec. to
toggle between CW and Memory keyer modes.
r While the quick set mode item “Q3” is selected in
CW mode, rotate main dial to select CW or CWå
mode.
•Push [DISPLAY] for 1 sec. to enter the quick set mode.
•Push [MENU] one or more times to select Q3.
•Push [DISPLAY] momentarily to return to normal oper-
ating mode.
t Rotate [AF] control to set audio to a comfortable
listening level.
y Rotate the main dial to simultaneously tune a de-
sired signal and its side tone.
u Set CW setting in the keyer set mode.
•Push [DISPLAY] once or twice to select M.
• Push [MENU] one or more times to select M4.
•Push [
(F-2)KEY] for 1 sec. to enter the keyer set mode.
(p. 32)
i Set CW break-in operation as semi break-in, full
break-in or OFF.
•Push [MENU] one or more times to select “K1 BK-
IN.”
•Rotate the main dial to select CW break-in operation.
➧ FULL: full break-in
➧ on : semi break-in
➧ OFF : no break-in (ACC socket connection is neces-
sary as at previous page.)
o Set the CW delay time when semi break-in opera-
tion is selected.
•Push [MENU] one or more times to select “K2 BK-
IN DELAY.”
•Rotate the main dial to set the desired delay time (see
p. 32 for details).
!0 Keying to transmit, use the electric keyer or pad-
dle to key your CW signals.
• The TX indicator lights red.
•The Po meter indicates transmitted CW signal
strength.
!1 Release keying to return to receive.
