DV MODE OPERATION (Optional UT-121 is required for IC-91A)
7
■ Digital repeater operation
Repeater call signs must be programmed for repeater opera-
tion in both digital voice and low-speed data communications.
DD
Repeater call sign programming
q Select B band as the main band. (p. 14)
w Enter “R1” or “R2” in call sign set mode.
• RPT1 or RPT2 CALL SIGN screen is displayed.
e Rotate [DIAL]
†
to select the desired call sign memory,
“R01” to “R60.”
r Push [
≈≈
](6) to enter call sign programming mode.
• The 1st digit blinks.
t Rotate [DIAL]
†
to select the desired character or code.
• Push [A/a](3) to change the character group from “AB” (alpha-
betical characters; capital letters), “12” (numbers) and “/” (sym-
bols) in sequence.
• Set “/” at the 1st digit then set the desired area repeater’s call
sign (in a different zone) for CQ call (“/” stands for “CQCQCQ”) in
a different zone operation. (p. 44)
y Push [
≈≈
](6) to select 2nd digit, then rotate [DIAL]
†
to se-
lect the desired character or code.
• Push [
≈≈
](6) to move the cursor right; push [
ΩΩ
](4) to move the
cursor left.
• 2nd digit blinks (1st digit stops blinking).
u Repeat the steps t and y to enter the desired repeater
call sign.
• Up to an 8-digit of call sign can be set.
• Push [7] when setting with the gateway connection if the se-
lected repeater has gateway capability. (The gateway connec-
tion can be set in RPT1 only when “NOT USE✱” is set to RPT2.)
• If an un-necessary character is entered, push [
≈≈
](6) or [
ΩΩ
](4) to
select the character, then push [CLR](1) to erase the selected
character, or push and hold [CLR](1) for 1 sec. to all characters
following the cursor.
i Push [ï](5) to store the programmed call sign and returns
to RPT1 or RPT2 CALL SIGN screen.
o Push [MENU/LOCK] to return to frequency indication.
