PANEL DESCRIPTION
New2001
■ Function display (Main screen) (Continued)
D Information area
The MMSI code* and the following indicators are displayed
in the Information area.
* ATIS code is displayed if only the ATIS code is entered in Dutch
and German version.
Indicator Description
Displayed when receiving a signal or when the
squelch is open.
Displayed while transmitting.
25W Displayed when high power is selected.
1W Displayed when low power is selected.
USA, INT,
CAN, WX,
ATIS, DSC
• Displays the selected channel group. (p. 15)
• “WX” is displayed when the weather channel
is selected.
Displayed when the transceiver receives valid
position and time data.
Blinks when invalid GPS data is being received.
• Displayed when there are unread DSC
messages.
• Blinks when a DSC message is received.
Displayed when the “CH Auto Switch” in DSC
Settings is set to an option except “Accept.”
Displayed when the external speaker is
selected. (p. 85)
Displayed when the Auto Foghorn function is
activated. (p. 67)
D Status area
The current status is displayed in the Status area.
Indicator Description
SCAN 16 Displayed during a Priority scan. (p. 23)*
SCAN Displayed during a Normal scan. (p. 23)*
DUAL 16 Displayed during Dualwatch. (p. 24)*
TRI 16 Displayed during Tri-watch. (p. 24)*
LOCAL Displayed when the Attenuator function is
turned ON.
*For only the USA version.
Displayed when in the RX Hailer mode.
(p. 66)
• Displayed when recorded audio is played or
stopped. (p. 70)
• Displayed when received audio is recorded.
(p. 70)
*Not usable in Dutch version.
