Icom IC-M803

5
PANEL DESCRIPTION
2
2
■ Optional HM-214M
1PTT SWITCH
 
2UP/DOWN KEYS [▲]/[▼]
Push to select an operating channel or group.
3PROGRAMMABLE KEY [P]
Push to activate the preset Software Key function.
Ask your dealer for details.
L You can reassign some Software Key functions to the
key. (p. 23)
4DSC SCAN KEY [D-SCAN]
Push to start the DSC scan. (p. 13)
1
2
3
4
MICROPHONE
■ Software Keys
Various often-used functions are assigned to the
Software Keys for easy access. The function’s icons
are displayed above the Software Keys, as shown
below.
D Selecting a Software Key function

functions that are assigned to the Software Keys.
Push the Software Key under the function’s icon to
select the function.
Soft Key 4Soft Key 3Soft Key 2Soft Key 1
Soft Key 5 Soft Key 8Soft Key 7Soft Key 6
Soft Key 12
Soft Key 11
Soft Key 10Soft Key 9
Soft Key 13
Soft Key 14 Soft Key 15 Soft Key 16
Soft Key 17
Soft Key 18 Soft Key 19 Soft Key 20
L 󰀨
transceiver version or presetting.
