2 PLC Program Transfer Function
29-16 WindO/I-NV4 User’s Manual
2.1 Supported PLCs
PLCs that support the PLC program transfer function are listed below.
The ports and functions supported are as follows.
*1 User program only
2 PLC Program Transfer Function
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
Manufacturer Series name
Supported system
(CPU unit)
Communication driver
IDEC
OpenNet Controller FC3A
• Serial Interface:
OpenNet, MICROSmart, SmartAXIS Pro/Lite (RS232C/485)
• Ethernet Interface:
OpenNet, MICROSmart, SmartAXIS Pro/Lite (Ethernet)
MICROSmart
FC4A
FC5A
FC6A
(FC6A-C*****E/
-C*****EJ only)
• Serial Interface:
MICROSmart(FC6A)(RS232C/485)
• Ethernet Interface:
MICROSmart(FC6A)(Ethernet)
FC6A
(FC6A-D****CEE
only)
MICROSmart(FC6A)(Ethernet)
SmartAXIS Pro/Lite FT1A OpenNet, MICROSmart, SmartAXIS Pro/Lite (Ethernet)
The corresponding device type differs depending on the communication driver which be used.
For FC6A type, please select MICROSmart (FC6A) (RS232C / 485), MICROSmart (FC6A) (Ethernet)
driver.
If use OpenNet, MICROSmart, SmartAXIS Pro / Lite (RS232C485), OpenNet, MICROSmart,
SmartAXIS Pro / Lite (Ethernet) driver, the device type is partially different. For details, refer to the
WindO/I-NV4 External Device Setup Manual.
Series Name Model Serial port
Download, Upload
*1
OpenNet Controller FC3A
Serial port 1 YES
Serial port 2 YES
MICROSmart
FC4A
Serial port 1 YES
Serial port 2 YES
FC5A
Ethernet port YES
Serial port 1 YES
Serial port 2 YES
Serial port 3 to 7 NO
FC6A
(FC6A-C*****E/-C*****EJ only)
Ethernet port 1 YES
FC6A-PH1 (HMI-Ethernet port) YES
Serial port 1 YES
Serial port 2 to 9 NO
FC6A
(FC6A-D****CEE only)
Ethernet port 1 YES
Ethernet port 2 YES
FC6A-PH1 (HMI-Ethernet port) YES
Serial port 1 to 33 NO
SmartAXIS Pro/Lite FT1A
Ethernet port YES
Serial port 2 NO
Serial port 3 NO
To Next Page
