2 Word Devices
33
Internal Devices
*5 HG2G-5T, HG1G/1P only
*6 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
*7 This is applicable for models with an audio interface only.
Device Address Function/Part
LSD59
*6
SD memory card download status
The following bit becomes to 1 while downloading to SD memory card by WindO/I-NV4.
The bit switched to 0 after downloading.
Bit 2: Recipe file
Bit 4: ZNV Project File
Bit 5: Picture file
Bit 8: Sound file
*7
Bit 9: ZLD Project File
LSD60 Reserved (for Line Chart)
LSD61 Reserved (for Trigger Condition)
LSD62 Reserved (for TCP/IP)
LSD63 to 64 Reserved
LSD65
The maximum number of screenshots in the in the SD memory card
*6
or the USB flash drive
*5
.
LSD66 Reserved
LSD67
Stores the connection status for TCP clients and the TCP server for the User Communication set to
the Ethernet interface.
Bit 0: User Communication 1
Bit 1: User Communication 2
Bit 2: User Communication 3
LSD68
When the value changes from 0 to 1, the connections for the TCP clients and the TCP server for the
User Communication set to the Ethernet interface are forcibly disconnected.
Bit 0: User Communication 1
Bit 1: User Communication 2
Bit 2: User Communication 3
LSD69 to 71 Reserved
LSD72
*7
Stores the currently played sound file number.
LSD73
*7
Stores the sound ID which could not be played by any errors.
LSD74 to 78 Reserved
LSD79 Quantity of Expansion I/O Modules
LSD80 to 96 Reserved
LSD97 Read scan communication time of External Device Communication 2 (msec.)
LSD98 Read scan communication time of External Device Communication 3 (msec.)
LSD99 Read scan communication time of External Device Communication 4 (msec.)
LSD100 Reserved (for O/I Link Communication)
LSD101 Polling period register for the O/I Link Slave
LSD102 Slave registration setting register for O/I Link Master
LSD103 Reserved (for O/I Link communication)
LSD104 Slave online information register for O/I Link Master
LSD105 Reserved (for O/I Link communication)
LSD106 Slave error information register for O/I Link Master
LSD107 Reserved (for O/I Link communication)
LSD108, 109 Reserved
LSD110, 111 Reserved (for Communication drivers)
LSD112 to 119
Register for Communication drivers
For details, refer to the WindO/I-NV4 External Device Setup Manual.
