IDEC MICRO/I HG1G-4VT22TF Series - Page 1599

WindO/I-NV4 User’s Manual 35-45
3 HG2G-5T, HG1G
35
MICRO/I Specifications
3.5 Specifications
■ Applicable Standards
■ Environmental Specifications
■ Electrical Specifications
■ Construction Specifications
*1 When using the HG2G-5T, HG1G as the EMC Standard Approved Products, refer to the precautions on the emission.
*2 When using a USB interface(USB2) by 151mA or more, operating temperature will be -20 to +50°C.
Safety Standard
UL508, ANSI/ISA 12.12.01,
CSA C22.2 No.142 (c-UL),
CSA C22.2 No.213 (c-UL)
EMC Standard
*1
IEC/EN 61131-2
Type No. HG2G-5T HG1G
Operating Temperature -20 to +60°C
-20 to +55°C
*2
Operating Humidity 10 to 90% RH (no condensation)
Storage Temperature -20 to +70°C
Storage Humidity 10 to 90% RH (no condensation)
Altitude 0 to 2000m
Pollution Degree 2
Corrosion Immunity Free from corrosive gases
Rated Voltage 12V DC / 24V DC
Power Consumption
8W maximum
When not using USB Interface (USB2): 4W maximum
Power Voltage Range 10.2V DC to 28.8V DC
Allowable Momentary Power
Interruption
10 ms maximum (Power supply: 20.4V DC to 28.8V DC)
1 ms maximum (Power supply: 10.2V DC to 20.4V DC)
Inrush Current 40A maximum
Dielectric Withstand Voltage 1000V AC, 10mA, 1 minute (between power and earth terminals)
Vibration
5 to 8.4Hz amplitude 3.5mm,
8.4 to 150Hz acceleration 9.8m/s
2
10 times on each of three mutually perpendicular axes (100 minutes)
(IEC61131-2)
Shock
147m/s
2
, 11ms (5 shocks on each of three mutually perpendicular axes)
(IEC61131-2)
